NAME        AC-EXO-444-KIT

VIDEO
VIDEO RESOLUTIONS        UP TO 4K/60HZ 4:4:4
HDR FORMATS        HDR10, HDR10+, DOLBY VISION, HLG
COLOR SPACE        YUV (COMPONENT), RGB (CSC: ITU-R BT.601, ITU-R BT.709, ITU-R BT.2020, DCI-P3 D65)
CHROMA SUBSAMPLING        4:4:4, 4:2:2, 4:2:0
COLOR BIT DEPTH        UP TO 16-BIT (1080P), UP TO 12-BIT (4K)
DOWN SCALING        4K TO 1080P

AUDIO
AUDIO FORMATS SUPPORTED (HDMI)        LPCM UP TO 7.1-CH @ 192KHZ 24-BIT, DOLBY DIGITAL, DOLBY DIGITAL PLUS, DOLBY TRUEHD, DOLBY ATMOS, DOLBY AC-4, DTS-DIGITAL SURROUND, DTS-ES DISCRETE, DTS-HD HIGH RES AUDIO, DTS-HD MASTER AUDIO, DTS:X
AUDIO FORMATS SUPPORTED (TOSLINK)        LPCM 2.0 CH, DOLBY DIGITAL, DTS 5.1, DOLBY DIGITAL PLUS (TX ONLY)

ARC / eARC
FORMATS SUPPORTED HDMI ARC/eARC OUT (TX)        LPCM 2.0 CH, LPCM 5.1 & 7.1, DOLBY DIGITAL, DTS 5.1, DOLBY DIGITAL PLUS, DOLBY TRUEHD, DTS-HD MASTER AUDIO, DTS:X, DOLBY ATMOS
FORMATS SUPPORTED TOSLINK OUT (TX)        LPCM 2.0 CH, DOLBY DIGITAL, DTS 5.1, DOLBY DIGITAL PLUS

FIBER
TYPE        SINGLE-MODE OS2
CONNECTOR        SIMPLEX LC (LUCENT CONNECTOR)
RECOMMENDED FIBER        OS2 CLEERLINE SSF™ SINGLE-MODE FIBER

DISTANCE
SINGLE-MODE (OS2)        UP TO 2 KM
HDMI IN/OUT (4K/60HZ 4:4:4)        UP TO 50 FT (USING BULLET TRAIN HDMI)
HDMI IN/OUT (AOC CABLE)        UP TO 130 FT (USING BULLET TRAIN AOC)

OTHER
BANDWIDTH        18 GBPS
HDCP        HDCP 2.3 AND EARLIER

PORTS
HDMI (TX & RX)        HDMI TYPE A 19-PIN, FEMALE
AUDIO (EXTRACTED DIGITAL)        TOSLINK (TX ONLY)
IR TX (TX & RX)        3.5MM MONO (2 CONDUCTOR)
IR RX (TX & RX)        3.5MM STEREO (3 CONDUCTOR)
RS-232 (TX & RX)        3-PIN EUROBLOCK
ISP/CTL        USB-C
POWER IN (TX & RX)        BARREL CONNECTOR

ENVIRONMENTAL
OPERATING TEMPERATURE        23° TO 125°F (-5° TO 51°C)
STORAGE TEMPERATURE        -4° TO 140°F (-20° TO 60°C)
HUMIDITY RANGE        5% TO 90% RH (NO CONDENSATION)

POWER
POWER CONSUMPTION (TOTAL)        6W MAXIMUM
POWER SUPPLY        INPUT: 100-240VAC ~ 50/60HZ | OUTPUT: 48VDC, 0.5A

PHYSICAL / DIMENSIONS
MOUNTING        MOUNTING BRACKETS (SCREWS INCLUDED)
DIMENSIONS (UNIT L/W/H)        MM: 82.55 X 130.175 X 20.638 | INCHES: 3.25 X 5.125 X 0.8125
DIMENSIONS (PACKAGED L/W/H)        MM: 136.53 X 192.1 X 84.14 | INCHES: 5.4 X 7.6 X 3.313
WEIGHT (UNIT)        0.6 LBS (0.27 KG)
WEIGHT (PACKAGED)        3.8 LBS (1.7 KG)

OTHER DETAILS
REGULATORY        CE / FCC
PRODUCT WARRANTY        10 YEARS
