NAME        AC-EXO-X-KIT

VIDEO
VIDEO RESOLUTIONS        UP TO 8K 60HZ 4:2:0 / 8K 30HZ 4:4:4 / 4K 120HZ
HDR FORMATS        HDR10, HDR10+, DOLBY VISION, HLG
COLOR SPACE        YUV (COMPONENT), RGB (CSC: REC.601, REC.709, BT2020, DCI, P3 D6500)
CHROMA SUBSAMPLING        4:4:4, 4:2:2, 4:2:0 SUPPORTED
COLOR BIT DEPTH        UP TO 16-BIT (1080P), UP TO 12-BIT (4K)
SCALING (OUTPUT 2 ONLY)        8K TO 4K, 8K TO 2K (1080P)

AUDIO
AUDIO FORMATS SUPPORTED HDMI        PCM 2.0 CH, LPCM 5.1 & 7.1, DOLBY DIGITAL, DTS 5.1, DOLBY DIGITAL PLUS, DOLBY TRUEHD, DTS-HD MASTER AUDIO, DTS-X, DOLBY ATMOS

FIBER
TYPE        MULTIMODE OM3
CONNECTOR        SIMPLEX LC (LUCENT CONNECTOR)
RECOMMENDED FIBER        OM3 CLEERLINE SFF™ FIBER

DISTANCE
OM2        UP TO 40M
OM3        UP TO 200M
OM4        UP TO 300M
HDMI IN/OUT (40GBPS)        UP TO 4M (USING BULLET TRAIN ULTRA HIGH SPEED HDMI CABLE)
HDMI IN/OUT (AOC CABLE)        UP TO 100M (USING BULLET TRAIN ULTRA HIGH SPEED HDMI CABLE)

OTHER
BANDWIDTH        40GBPS (FRL5)
HDCP        HDCP 2.3 AND EARLIER

PORTS
HDMI (TX & RX)        TYPE A
IR TRANSMIT (TX & RX)        3.5MM MONO JACK (TS)
IR RECEIVE (TX & RX)        3.5MM STEREO JACK (TRS)
RS-232 CONTROL (TX & RX)        3-PIN TERMINAL BLOCK
POWER (TX & RX)        2-PIN TERMINAL BLOCK, USB-C

ENVIRONMENTAL
OPERATING TEMPERATURE        23° TO 125°F (-5° TO 51°C)
STORAGE TEMPERATURE        -4° TO 140°F (-20° TO 60°C)
HUMIDITY RANGE        5–90% RH (NO CONDENSATION)

POWER
TOTAL POWER CONSUMPTION        2.5W MAXIMUM
POWER SUPPLY        INPUT: 48V 0.5A | OUTPUT: DC 5V 1A

DIMENSIONS
DIMENSIONS (UNIT H/W/D)        MM: 80.6 X 140 X 15.4 | INCHES: 3 X 5.5 X 0.6
DIMENSIONS (PACKAGED H/W/D)        MM: 135 X 194 X 84 | INCHES: 5.3 X 7.6 X 3.3
WEIGHT (UNIT)        0.55 LBS (0.25 KG)
WEIGHT (PACKAGED)        2.5 LBS (1.13 KG)
