Name        Kramer Electronics SL-1N
BIDIRECTIONAL PORTS        2 RS–232 serial on 3–pin terminal blocks, 1 K–NET on 4–pin terminal block connector, 1 Ethernet on an RJ–45 connector, 1 Mini USB connector for local programming services
INPUTS        1 built–in IR sensor, 1 IR–in on 3.5mm mini–jack (for learning)
OUTPUTS        2 IR–out and 3 relays (36V AC or DC, 2A, 60VAC maximum on non–inductive load) on 2–pin terminal block connectors
INDICATORS        LED indicator for each port and function
POWER CONSUMPTION        12V DC, 180mA
OPERATING TEMPERATURE        0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE        –40° to +70°C (–40° to 158°F)
HUMIDITY        10% to 90%, RHL non–condensing
INCLUDED ACCESSORIES        Power supply
Product Dimensions        12.00 cm x 7.15 cm x 2.44 cm (4.72" x 2.81" x 0.96") W, D, H
Product Weight        0.2 kg (0.4 lbs) approx.
Shipping Dimensions        49.00 cm x 18.60 cm x 58.80 cm (19.29" x 7.32" x 23.15") W, D, H
Shipping Weight        0.5 kg (1.2 lbs) approx.
